Industrial panel-mount projected capacitive touch displays. IP-65 front panel, VGA/HDMI input, USB touch interface. Available 12.1″ – 21.5″.
4 : 3
12.1″ Panel Mount
| Resolution | 1024 × 768 (XGA) |
| Brightness | 500 cd/m² std · 1,000 cd/m² high-bright |
| Contrast | 1000:1 (Typ.) |
| Viewing Angle | 89° / 89° / 89° / 89° |
| Response Time | 25 ms (Typ.) |
| Backlight | WLED, integrated driver · ≥30,000 hrs |
| Physical Size | 260.5 × 204.0 × 8.9 mm |
| Video Input | VGA / HDMI |
| Touch | PCAP · USB Interface |
| OSD | 5 Keys |
| Operating Temp | −30°C ~ 70°C |
| Power | DC 12V · AC 100~240V adapter opt. |
| Glass | AG / AR |
| Certifications | CE · FCC · RoHS · REACH |
4 : 3
15″ Panel Mount
| Resolution | 1024 × 768 (XGA) |
| Brightness | 350 cd/m² std · 1,000 cd/m² high-bright |
| Contrast | 800:1 (Typ.) |
| Viewing Angle | 80° / 80° / 70° / 80° (TN panel) |
| Response Time | 8 ms (Typ.) |
| Backlight | WLED, integrated driver · ≥50,000 hrs |
| Physical Size | 326.5 × 253.5 × 10.0 mm |
| Video Input | VGA / HDMI |
| Touch | PCAP · USB Interface |
| OSD | 5 Keys |
| Operating Temp | 0°C ~ 65°C |
| Power | DC 12V · AC 100~240V adapter opt. |
| Glass | AG / AR |
| Certifications | CE · FCC · RoHS · REACH |
16 : 9
15.6″ Panel Mount
| Resolution | 1920 × 1080 (FHD) |
| Brightness | 250 cd/m² std · 1,000 cd/m² high-bright |
| Contrast | 800:1 (Typ.) |
| Viewing Angle | 85° / 85° / 85° / 85° |
| Response Time | 25 ms (Typ.) |
| Backlight | WLED, integrated driver · ≥30,000 hrs |
| Physical Size | 359.5 × 223.8 × 3.2 mm |
| Video Input | VGA / HDMI |
| Touch | PCAP · USB Interface |
| OSD | 5 Keys |
| Operating Temp | 0°C ~ 50°C |
| Power | DC 12V · AC 100~240V adapter opt. |
| Glass | AG / AR |
| Certifications | CE · FCC · RoHS · REACH |
5 : 4
17″ Panel Mount
| Resolution | 1280 × 1024 (SXGA) |
| Brightness | 250 cd/m² std · 1,000 cd/m² high-bright |
| Contrast | 1000:1 (Typ.) |
| Viewing Angle | 85° / 85° / 80° / 80° (TN panel) |
| Response Time | 5 ms Tr+Td (Typ.) |
| Backlight | WLED 9S4P, external driver req. · ≥30,000 hrs |
| Physical Size | 358.5 × 296.5 × 10.8 mm |
| Video Input | VGA / HDMI |
| Touch | PCAP · USB Interface |
| OSD | 5 Keys |
| Operating Temp | 0°C ~ 50°C |
| Power | DC 12V · AC 100~240V adapter opt. |
| Glass | AG / AR |
| Certifications | CE · FCC · RoHS · REACH |
16 : 9
18.5″ Panel Mount
| Resolution | 1920 × 1080 (FHD) |
| Brightness | 500 cd/m² std · 1,000 cd/m² high-bright |
| Contrast | 1200:1 (Typ.) |
| Viewing Angle | 85° / 85° / 85° / 85° |
| Response Time | 30 ms (Typ.) |
| Backlight | WLED 14S4P, integrated driver · ≥30,000 hrs |
| Physical Size | 430.4 × 254.6 × 14.25 mm |
| Video Input | VGA / HDMI |
| Touch | PCAP · USB Interface |
| OSD | 5 Keys |
| Operating Temp | −30°C ~ 80°C |
| Power | DC 12V · AC 100~240V adapter opt. |
| Glass | AG / AR |
| Certifications | CE · FCC · RoHS · REACH |
16 : 9
21.5″ Panel Mount
| Resolution | 1920 × 1080 (FHD) |
| Brightness | 250 cd/m² std · 1,000 cd/m² high-bright |
| Contrast | 1000:1 (Typ.) |
| Viewing Angle | 89° / 89° / 89° / 89° |
| Response Time | 25 ms (Typ.) |
| Backlight | WLED, integrated driver · ≥50,000 hrs |
| Physical Size | 495.6 × 292.2 mm (depth TBD) |
| Video Input | VGA / HDMI |
| Touch | PCAP · USB Interface |
| OSD | 5 Keys |
| Operating Temp | 0°C ~ 60°C |
| Power | DC 12V · AC 100~240V adapter opt. |
| Glass | AG / AR |
| Certifications | CE · FCC · RoHS · REACH |
High-bright option, AG/AR glass, extended temperature ranges — contact our sales team.
